''' <summary>
''' Recognizes the form with a group of marks (OMR bubbles).
''' </summary>
''' <param name="formRecognitionManager">The form recognition manager.</param>
''' <param name="image">The image.</param>
Public Shared Sub RecognizeFormWithOmrFieldTables(formRecognitionManager As Vintasoft.Imaging.FormsProcessing.FormRecognitionManager, image As Vintasoft.Imaging.VintasoftImage)
    ' if your form template contains OCR fields,
    ' make sure OCR engine manager is initialized before recognition
    ' (otherwise recognition will return null (Nothing)),
    ' see OCR field recognition examples

    ' recognize filled form in an image
    Dim recognitionResult As Vintasoft.Imaging.FormsProcessing.FormRecognitionResult = formRecognitionManager.Recognize(image)

    ' get the result of image comparison
    Dim imageCompareResult As Vintasoft.Imaging.FormsProcessing.TemplateMatching.ImageImprintCompareResult = recognitionResult.TemplateMatchingResult.ImageCompareResult
    ' if result is not reliable
    If Not imageCompareResult.IsReliable Then
        ' matching template is not found
        System.Console.WriteLine("Matching template is not found.")
    Else
        ' get recognized page
        Dim recognizedPage As Vintasoft.Imaging.FormsProcessing.FormRecognition.FormPage = recognitionResult.RecognizedPage
        ' get form field count
        If recognizedPage.Items.Count = 0 Then
            System.Console.WriteLine("No form fields were recognized.")
        Else
            System.Console.WriteLine(String.Format("Recognized form field count: {0}", recognizedPage.Items.Count))
            ' for each recognized form field
            For Each recognizedField As Vintasoft.Imaging.FormsProcessing.FormRecognition.FormField In recognizedPage.Items
                If TypeOf recognizedField Is Vintasoft.Imaging.FormsProcessing.FormRecognition.Omr.OmrFieldTable Then
                    Dim omrFieldTable As Vintasoft.Imaging.FormsProcessing.FormRecognition.Omr.OmrFieldTable = DirectCast(recognizedField, Vintasoft.Imaging.FormsProcessing.FormRecognition.Omr.OmrFieldTable)
                    Dim omrTemplateTable As Vintasoft.Imaging.FormsProcessing.FormRecognition.Omr.OmrFieldTemplateTable = TryCast(omrFieldTable.FieldTemplate, Vintasoft.Imaging.FormsProcessing.FormRecognition.Omr.OmrFieldTemplateTable)
                    ' write field info
                    System.Console.WriteLine(String.Format("  OMR field table: name: {0}; value: {1}; confidence: {2:F1}%; row count: {3}; column count: {4}", omrFieldTable.Name, omrFieldTable.Value, omrFieldTable.Confidence * 100, omrTemplateTable.RowCount, omrTemplateTable.ColumnCount))
                End If
            Next
        End If
    End If
End Sub

/// <summary>
/// Recognizes the form with a group of marks (OMR bubbles).
/// </summary>
/// <param name="formRecognitionManager">The form recognition manager.</param>
/// <param name="image">The image.</param>
public static void RecognizeFormWithOmrFieldTables(
    Vintasoft.Imaging.FormsProcessing.FormRecognitionManager formRecognitionManager,
    Vintasoft.Imaging.VintasoftImage image)
{
    // if your form template contains OCR fields,
    // make sure OCR engine manager is initialized before recognition
    // (otherwise recognition will return null (Nothing)),
    // see OCR field recognition examples

    // recognize filled form in an image
    Vintasoft.Imaging.FormsProcessing.FormRecognitionResult recognitionResult =
        formRecognitionManager.Recognize(image);

    // get the result of image comparison
    Vintasoft.Imaging.FormsProcessing.TemplateMatching.ImageImprintCompareResult imageCompareResult =
        recognitionResult.TemplateMatchingResult.ImageCompareResult;
    // if result is not reliable
    if (!imageCompareResult.IsReliable)
    {
        // matching template is not found
        System.Console.WriteLine("Matching template is not found.");
    }
    else
    {
        // get recognized page
        Vintasoft.Imaging.FormsProcessing.FormRecognition.FormPage recognizedPage =
            recognitionResult.RecognizedPage;
        // get form field count
        if (recognizedPage.Items.Count == 0)
        {
            System.Console.WriteLine("No form fields were recognized.");
        }
        else
        {
            System.Console.WriteLine(string.Format(
                "Recognized form field count: {0}",
                recognizedPage.Items.Count));
            // for each recognized form field
            foreach (Vintasoft.Imaging.FormsProcessing.FormRecognition.FormField recognizedField in recognizedPage.Items)
            {
                if (recognizedField is Vintasoft.Imaging.FormsProcessing.FormRecognition.Omr.OmrFieldTable)
                {
                    Vintasoft.Imaging.FormsProcessing.FormRecognition.Omr.OmrFieldTable omrFieldTable =
                        (Vintasoft.Imaging.FormsProcessing.FormRecognition.Omr.OmrFieldTable)recognizedField;
                    Vintasoft.Imaging.FormsProcessing.FormRecognition.Omr.OmrFieldTemplateTable omrTemplateTable =
                        omrFieldTable.FieldTemplate as Vintasoft.Imaging.FormsProcessing.FormRecognition.Omr.OmrFieldTemplateTable;
                    // write field info
                    System.Console.WriteLine(string.Format(
                        "  OMR field table: name: {0}; value: {1}; confidence: {2:F1}%; row count: {3}; column count: {4}",
                        omrFieldTable.Name,
                        omrFieldTable.Value,
                        omrFieldTable.Confidence * 100,
                        omrTemplateTable.RowCount,
                        omrTemplateTable.ColumnCount));
                }
            }
        }
    }
}
